TB20J Plus Operation Manual
19
© Feb. 2023
4 TECHNICAL PARAMETERS
4.1 MACHINE SPECIFICATIONS
Table 4-1 TB20J Plus specifications
ITEM
TB20J Plus (METRIC) TB660J Plus (IMPERIAL)
Product Category
Power type Diesel engine-powered
Outrigger type Oscillating outrigger
DIMENSION
Max. platform height
20m 65ft 7in
Max. working height
22m 72ft 2in
Max. horizontal reach (restricted/
unrestricted)
14.6m/16.1m 47ft 11in/52ft 10in
Max. horizontal working envelope
(restricted/unrestricted)
15.2m/16.7m 49ft 10in/54ft 9in
Overall length (stowed)
9.99m 32ft 9in
Overall length (transport)
8.12m 26ft 8in
Overall width (stowed)
2.49m 8ft 2in
Overall width (transport)
2.49m 8ft 2in
Overall height (stowed)
2.79m 9ft 2in
Overall height (transport)
2.77m 9ft 1in
Wheelbase 2.49m 8ft 2in
Ground clearance 0.46m 1ft 6in
Platform dimension (L×W×H)
Options
1.45m×0.85m×1.1m
1.83m×0.85m×1.1m
2.44m×0.91m×1.1m
Options
4ft 9in×2ft 9in×3ft 7in
6ft×2ft 9in×3ft 7in
8ft×3ft×3ft 7in
PERFORMANCE
Rated platform load capacity
(restricted/unrestricted)
454kg/300kg
1000lb/661lb
Max. number of allowed people on
the platform (restricted/unrestricted)
3 persons/2 persons
Drive speed (stowed)
0～4.8km/h
0～3mph
Drive speed (raised)
0～1.1km/h
0～0.68mph
Gradeability (4WD)
45%
Turntable rotation (angle/continuity)
360°/continuous
Platform rotation angle
160°
