© Feb. 2023
70
TB20J Plus Operation Manual
OPTIONS
Removal instructions
Disassemble the pipe support device in the reverse or-
der of the installation instructions.
Instructions for Use
Tipping Hazard
• The weight of the pipe support
assembly and the load on the pipe
support will reduce the rated load
capacity of the platform, so the
pipe support device and its load
must be taken into account in the
total load of the platform.
• When the weight of the pipe sup-
port device and the load on the
pipe support is too heavy, the
maximum number of allowed peo-
ple on the platform needs to be
reduced.
Table 11-3
Maximum load capacity
of pipe support device
100kg (220lbs)
Weight of pipe support
assembly
6kg (13lbs)
After the pipe support device is installed, follow the be-
low instructions for use:
1. Ensure that the pipe support device has been in-
stalled exactly as required and has been secured to
the platform guardrail.
2. Place the load on the pipe support device, ensuring
that the load is parallel with the platform in terms of
length.
3. Ensure that the load center is on the same level as
the center of the pipe support device.
4. Use the straps equipped with the device to secure
the load to the two pipe supports.
5. Gently push and pull the load to ensure that the load
is securely secured to the pipe supports.
6. When the machine is working, ensure that the load
is always firmly placed.
11.3 GLASS PANEL BRACKET
DEVICE
Self-propelled boom-supported elevating work platforms
are designed to transport people, tools and materials to
aerial workplaces. When panels need to be transported
to aerial workplaces, they can be placed on the glass
panel bracket device and then transported after secured
to the device.
To Next Page
