6 CONTROLLERS AND INDICATORS
This chapter provides the brief introduction of switches,
handles and displays on the ground controller and plat-
form controller. Refer to the Operation Instructions
section for the detailed description.
NOTICE
The manufacturer does not have direct control over
the application and operation of the machine. Users
and operators are responsible for complying with the
applicable safety specifications.
6.1 GROUND CONTROLLER
(EQUIPPED WITH DEUTZ ENGINE)
Fig 1
OFF
ON
1
2
3
4
5
6
7
8 9
10
12
13
11
- +
DC FE
14
15
16
17
18
