OPERATION INSTRUCTIONS
TB20J Plus Operation Manual
45
© Feb. 2023
boom rotation control handle to the right, and the jib
boom will rotate counterclockwise. (if equipped)
7.11 PLATFORM MOVEMENTS
The platform leveling function can only be used to
slightly adjust the platform levelness in situations
such as traveling up/down slopes. Improper use
may cause loads/people to move or fall.
Perform operation from the ground:
1. Level the platform upward: Move and hold the
enable switch, push upward the platform leveling
switch, and the platform will be leveled upward.
2. Level the platform downward: Move and hold the
enable switch, pull downward the platform leveling
switch, and the platform will be leveled downward.
3. Rotate the platform clockwise: Move and hold
the enable switch, pull downward the platform rota-
tion switch, and the platform will rotate clockwise.
4. Rotate the platform anti-clockwise: Move and
hold the enable switch, push upward the platform
rotation switch, and the platform will rotate anti-
clockwise.
Perform operation from the platform:
1. Level the platform upward: Depress the foot
switch, push upward the platform leveling switch,
and the platform will be leveled upward.
2. Level the platform downward: Depress the foot
switch, pull downward the platform leveling switch,
and the platform will be leveled downward.
3. Rotate the platform clockwise: Depress the foot
switch, push the platform rotation switch to the left,
and the platform will rotate clockwise.
4. Rotate the platform anti-clockwise: Depress the
foot switch, push the platform rotation switch to the
right, and the platform will rotate anti-clockwise.
7.12 AUXILIARY POWER
NOTICE
• When the emergency power is in use, do not per-
form two or more functions at the same time, be-
cause certain function operation may have no
response due to small flow in the emergency mo-
tor or pump.
• The emergency power switch can only be used for
a short time (to fully lower and retract the platform
from the maximum angle and maximum length)
when the main power source is not working, be-
cause long-time operation may bring damage to
the motor.
In the event of main power source failure, the auxiliary
power can be used to perform the desired function
operation.
Perform operation from the ground:
Move and hold the emergency power switch, activate
the desired movement switch to perform the required
function operation.
Perform operation from the platform:
Depress the foot switch, move and hold the emergency
power switch, and activate the desired movement switch
to perform the required function operation.
7.13 SHUTDOWN AND PARKING
1. Park the machine on a solid, flat, and level surface,
and make sure the area is adequately protected.
2. Make sure the boom is fully retracted and positioned
above the rear-wheel drive axle, and make sure all
panels and gates are closed and secured.
3. Remove all loads on the platform.
4. If equipped with an engine, idle the engine for 3min
～5min to reduce its internal temperature.
5. Press the emergency stop button on the ground
controller and platform controller, turn the key switch
to the OFF position and remove the key.
6. Cover the platform controller protective cover to pro-
tect the platform controller, handles, switches, and
panels from harsh environments.
7. If the machine is to be left unused for a long time,
press the main power switch.
