Sinoboom TB20J Plus - Device Components

OPTIONS
TB20J Plus Operation Manual
71
© Feb. 2023
Unsafe Operation Hazard
• Except for designated models
and corresponding markets, it is
forbidden to install the glass pan-
el bracket device on other Sino-
boom products or any models in
other markets.
• Before using the glass panel
bracket device, the safety rules
Unsafe Operation Hazard
and all operating instructions
should be read, understood and
observed. This manual should al-
ways be kept with the glass panel
bracket device as a part of it.
Device Components
Fig 4
Table 11-4
No. Part Number Part Name
Quantity Comment
1 216030003000 Anti-collision hose
5
2 215020000011 Screw M6×16-A2-70 GB/T 70.1 12
3 105064043024 Cushion block 6
4 215030000004
Nut M6-A2-70 GB/T 6170
20
5
105064043178
Cushion plate
4
7
3
6
4
8
2
4
1
5
9
