Sinoboom TB20J Plus - Device Components

© Feb. 2023
68
TB20J Plus Operation Manual
OPTIONS
Unsafe Operation Hazard
• Except for designated models
and corresponding markets, it is
forbidden to install the pipe sup-
port device on other Sinoboom
products or any models in other
markets.
• Before using the pipe support de-
vice, the safety rules and all
Unsafe Operation Hazard
operating instructions should be
read, understood and observed.
This manual should always be
kept with the pipe support device
as a part of it.
Device Components
Fig 2
Table 11-2
No. Part Number Part Name
Quantity Comment
1 215030000107
Nut M6-8-ZnD GB/T 6183
4
2 105064043177 Pipe seal 4
3 215010000055 Bolt M6×50-A2-70 GB/T 5783
4
5
4
2
2
3
1
6
7
