Disassemble the glass panel bracket device in the re-
verse order of the installation instructions.
Instructions for Use
Tipping Hazard
• When the wind speed in the work-
ing environment exceeds 12.5m/s
(28mph), please do not use the
glass panel bracket device.
• The weight of the glass panel
bracket device and the load on the
glass panel bracket will reduce
the rated load capacity of the plat-
form, so the glass panel bracket
device and its load must be taken
into account in the total load of
the platform.
• When the weight of the glass pan-
el bracket device and the load on
the glass panel bracket is too
heavy, the maximum number of al-
lowed people on the platform
needs to be reduced.
• The area of the glass panel will in-
crease the machine’s area ex-
posed to the wind, which will
reduce the stability of the
machine.
• Only use the glass panel bracket
device when the machine is on
flat, solid ground.
Table 11-5
Maximum load capacity of
glass panel bracket device
115kg (253.5lbs)
Weight of glass panel bracket
device
15.2kg (33.5lbs)
Maximum allowable wind
speed
12.5m/s (28mph)
Maximum allowable area for
carrying glass panel
0.17㎡
(1.83sq.ft)
Maximum allowable vertical
height for carrying glass
panel
1.2m (3ft 11in)
1. Ensure that the glass panel bracket device is in-
stalled exactly as required and secured to the
platform.
2. Place the load on the glass panel bracket, ensuring
that the load is parallel with the glass panel bracket
in terms of length.
3. Ensure that the load center is on the same level as
the center of the glass panel bracket.
4. Use straps to secure the load to the platform.
5. Gently push and pull the load to ensure that the load
is securely secured to the platform.
6. When the machine is working, ensure that the load
is always firmly placed.
NOTICE
Make sure to maintain an appropriate distance
between the load and the gate bar to prevent the gate
bar from causing scratching, squeezing and other
damage to the load.
11.4 PLATFORM FENCE DEVICE
There are two types of platform fence devices: half-
height platform fence device and full-height platform
fence device. This device can effectively prevent tools
or other objects in the platform from falling.
