CONTROLLERS AND INDICATORS
Table 6-3 (Continued)
No. Indication
Description
10
Alarm message
Press the key to the right of the icon to enter alarm message
interface to check the system alarm or fault state.
11 Fault alarm indicator
This icon lights up to indicate a system failure.
12
Glow plug indicator
This icon lights up to indicate that the engine is taking in air for
preheating.
13
Low fuel/battery level indicator This icon lights up to indicate low fuel/battery level.
14
Engine oil pressure alarm indicator
This icon lights up to indicate that the engine oil pressure is
too low.
15
Charging indicator This icon lights up to indicate that the machine is charging.
16
Water temp alarm indicator
This icon lights up to indicate that the engine water tempera-
ture is too high.
17
Hydraulic generator/inverter ON
indicator
This icon lights up to indicate that the hydraulic generator/in-
verter is turned on.
18 FE mode indicator
This icon lights up to indicate that the machine is in FE mode.
19 Chassis tilt indicator
This icon lights up to indicate that the chassis tilt angle ex-
ceeds the maximum allowable tilt angle.
20 Platform tilt alarm indicator
This icon lights up to indicate that the platform is tilted.
21
Heavy load indicator
This icon lights up to indicate that the load on the platform ex-
ceeds the light load.
22 Overload alarm indicator
This icon lights up to indicate that the load on the platform ex-
ceeds its rated load.
23
Fully-extended axle indicator
This icon lights up to indicate that the outrigger telescopic axle
has been fully extended.
24
Fully-retracted axle indicator
This icon lights up to indicate that the outrigger telescopic axle
has been fully retracted.
25
High engine speed indicator
This icon lights up to indicate that the engine is running at high
speed.
26
Low engine speed
This icon lights up to indicate that the engine is running at low
speed.
27
Operating position
This icon lights up to indicate that the machine is in operating
position.
28
Non-operating position
This icon lights up to indicate that the machine is in non-oper-
ating position.
29 Boom horizontal reach
To display the horizontal reach from the platform outer edge to
the rotation center.
30
Boom’s angle relative to the horizontal
To display the boom’s angle relative to the horizontal, with the
angle above the horizontal as positive value, and the angle be-
low the horizontal as negative value.
31
Boom length To display the current boom length.
32
Platform height To display the current platform height.
