© Feb. 2023 52 TB20J Plus Operation Manual
DIAGRAM OF DECALS POSITIONS
No. GB CE-Metric
CE-Imperial
AS CSA ANSI
Description
105050103002 105050103005 105050103017 105050103016 105050103014 105050103010
General diagram of dec-
als positions
1 104011100002 104011100002 104011100002 104011100002 104011100002 104011100002
Decal-Lifting point
2 104011100014 104011100014 104011100014 104011100014 104011100014 104011100014
Decal-Explosion hazard
3 105045103002 105045103002 105045103002 105045103002 105045103002 105045103002
LOGO-Symbol (large)
4 104011100013 104011100013 104011100013 104011100013 104011100013 104011100013
Decal-Electrocution
hazard
5 104011100007 104011100007 104011100007 104011100007 104011100007 104011100007
Decal-Tipping hazard
6 / / / / 101040103015 101040103015
Decal-Annual inspection
date
7 104011100006 104011100006 104011100006 104011100006 104011100006 104011100006
Decal-Compartment
overhaul
8 104011100020 104011100020 104011100020 104011100020 104011100020 104011100020
Decal-General safety
instructions
9 104011100022 104011100022 104011100022 104011100022 104011100022 104011100022
Decal-Turntable rotation
pin
10 104011100016 104011100016 104011100016 104011100016 104011100016 104011100016
Decal-Emergency stop
button
11 104011100011 104011100011 104011100011 104011100011 104011100011 104011100011
Decal-Crushing hazard
12 104011100001 104011100001 104011100001 104011100001 104011100001 104011100001
Decal-Tipping hazard
13 105050103009 105050103009 105050103009 105050103009 113002103008 113002103008
Decal-Load on ground of
6740kg
14 103003100004 105001100050 105001100050 105001100050 105001100050 105001100050 Decal-Contact information
15 105050103000 105050103000 105050103012 105050103000 105050103012 105050103012
Decal-Trade ID XX
(small)
16 105057103001 105057103001 105057103001 105057103001 105057103001 105057103001
LOGO-SINOBOOM
(large)
17 105050103001 105050103001 105050103011 105050103001 105050103011 105050103011
Decal-TB20J Plus
Decal-TB660J Plus
18 105001100057 103011103012 103011103012 105045103004 103004103004 103004103004
Nameplate
19 215050000001 215050000001 215050000001 215050000001 215050000001 215050000001 Blind rivet 3×8-ZnD
20 104011100005 104011100005 104011100005 104011100005 104011100005 104011100005
Decal-Explosion hazard
