Section 4 – Troubleshooting Information Electrical System - CE & AS
31. Loose or broken wire #60 from platform terminal
block to fuel select switch S26.
Check continuity. Replace if defective.
32. Defective fuel select switch S26. Check switch. Replace if defective.
33. Loose or broken wire #11 from fuel select
switch S26 to plug B pin #15 in platform control
console.
Check continuity. Replace if defective.
34. Loose or broken wire #11 in boom cable B or its
connectors.
Check continuity between pins #15 on cable B.
Check for loose or corroded connections on cable
connectors. Replace if wire is defective.
35. Loose or broken wire #11 from plug B pin #15 to
engine harness plug.
Check continuity. Replace if defective.
36. Loose or broken wire #11 from engine harness
plug to GM engine connector 1.
Check continuity. Replace if defective.
37. Loose or broken tan/brown wire from GM engine
connector 1 to ECU connector pin #42.
Check continuity. Replace if defective.
38. Loose or broken pink/tan wire from fuse F7 to
propane lock off 2P-56.
Check continuity. Replace if defective.
39. Loose or broken white/black wire from ECU
connector pin #75 to propane lock off 2P-56.
Check continuity. Replace if defective.
40. Defective propane lock off 2P-56. Check lock off. Replace if defective.
41. Loose or broken pink/dark green wire from fuse
F10 to fuse F9.
Check continuity. Replace if defective.
42. Defective fuse F9. Check fuse. Replace if defective.
43. Loose or broken red/light blue wire from fuse F9
to propane regulator PRV1.
Check continuity. Replace if defective.
44. Loose or broken black wire from engine ground
to propane regulator PRV1.
Check continuity. Replace if defective.
4.3-5 Glow Plug Circuit Inoperative - Deutz D2011 diesel engine
1. Defective glow plug fuse FU1 50 amp. Check fuse. Replace if defective.
2. Loose or broken wire #03 from start solenoid
57CCR to fuse holder FU1.
Check continuity. Replace if defective.
3. Loose or broken wire #11A from fuse holder FU1
to relay 54ACR.
Check continuity. Replace if defective.
4. Loose or broken wire #11B from relay 54ACR to
glow plugs.
Check continuity. Replace if defective.
