Skyjack SJ46 AJ+ Service Manual

187
229042ABASJ46 AJ+, SJ46 AJ, SJ51 AJ
Hydraulic System Section 4 – Troubleshooting Information
4.5-17 No Platform Rotation Right - CE & AS
1. Stuck or defective platform rotate enable valve
2H-36A.
Clean valve. Check O-rings on valve. Check
operation of valve. Repair or replace valve as
required.
2. Plugged or defective orifice OR1. Check orifice. Replace if plugged or defective.
3. Stuck or defective differential pressure sensing
valve DSV5.
Clean valve. Check O-rings on valve. Check
operation of valve. Repair or replace valve as
required.
4. Stuck or defective check valve CV12. Clean valve. Check operation of valve. Repair or
replace valve as required.
5. Stuck or defective platform rotate right valve 4H-
37.
Clean valve. Check operation of valve. Repair or
replace valve as required.
6. Stuck or defective counterbalance valve CB14. Clean valve. Check O-rings on valve. Repair or
replace valve as required.
7. Defective rotary actuator RA1. Check actuator. Repair or replace as necessary.
4.5-18 No Platform Rotation Left - ANSI/CSA
1. Stuck or defective platform rotate enable valve
2H-42.
Clean valve. Check O-rings on valve. Check
operation of valve. Repair or replace valve as
required.
2. Stuck or defective differential pressure sensing
valve DSV5.
Clean valve. Check O-rings on valve. Check
operation of valve. Repair or replace valve as
required.
3. Stuck or defective check valve CV12. Clean valve. Check operation of valve. Repair or
replace valve as required.
4. Stuck or defective platform rotate right valve 4H-
36.
Clean valve. Check operation of valve. Repair or
replace valve as required.
5. Stuck or defective counterbalance valve CB15. Clean valve. Check O-rings on valve. Repair or
replace valve as required.
6. Defective rotary actuator RA1. Check actuator. Repair or replace as necessary.
