Skyjack SJ46 AJ+ - Specifications & Features - Dimensions & Speeds

45
229042ABASJ46 AJ+, SJ46 AJ, SJ51 AJ
Specifications & Features - Dimensions & Speeds Section 2 – Maintenance Tables and Diagrams
SJ46 AJ+ ANSI/CSA SJ46 AJ CE & AS SJ51 AJ CE & AS
Height & Reach
Working Height 15.93 m 52' 3-1/4" 16.10 m 17.55 m
Platform Elevated Height 14.10 m 46' 3-1/4" 14.10 m 15.55 m
Drive Height Driveable at all heights
Horizontal Reach - Maximum 7.54 m 24' 8-3/4" 7.54 m 9.03 m
Horizontal Reach at Max Height 2.47 m 8' 1" 2.47 m 2.86 m
Tailswing 0 0 0 0
Up and Over Clearance - Platform 7.53 m 24' 8-3/4" 7.53 m 7.53 m
Up and Over Clearance - Main Boom 7.45 m 24' 5-1/4" 7.45 m 7.45 m
Platform
Platform Size
0.76 x 1.52 m
0.76 x 1.83 m
30" x 60"
30" x 72"
0.76 m x 1.52 m
0.76 m x 1.83 m
0.76 m x 1.52 m
0.76 m x 1.83 m
Platform Rotation 178° 178° 178° 178°
Platform Height - Stowed 0.28 m 11" 0.25 m 0.25 m
Platform Height - Overall 1.35 m 53" 1.33 m 1.33 m
Railing Height - Platform 1.11 m 44" 1.10 m 1.10 m
Dimensional Data
Height - Stowed 2.06 m 6' 9" 2.06 m 2.06 m
Length - Stowed 6.35 m 20' 10" 6.35 m 7.10 m
Width 2.29 m 7' 6" 2.29 m 2.29 m
Wheelbase 2.03 m 6' 8" 2.03 m 2.03 m
Ground Clearance - Chassis 0.39 m 15-1/4" 0.39 m 0.39 m
Ground Clearance - Axle 0.33 m (front) 13" (front) 0.27 m (rear) 0.27 m (rear)
Axle Oscillation 3.25° 3.25° 3.25° 3.25°
Turning Radius - Inside 1.50 m 4' 11-1/4" 1.50 m 1.50 m
Turning Radius - Outside 4.34 m 14' 3" 4.34 m 4.34 m
Turret Rotation 360° 360° 360° 360°
Lift Capacity
Max Lift Capacity without attachment 300 kg 660 lb 227 kg 227 kg
Max Persons without Attachment 2 2 2 2
Max Lift Capacity with attachment 272 kg 600 lb 227 kg 227 kg
Max Persons with Attachment 1 1 2 2
Jib
Jib Length - Stowed 1.42 m 55-3/4" 1.42 m 1.42 m
2041AA
Table 2.13 Specifications & Features - Dimensions & Speeds
