Skyjack SJ46 AJ+ Service Manual

A B C D E F G H
V
Z
Y
X
W
76
229042ABA SJ46 AJ+, SJ46 AJ, SJ51 AJ
M218405AE
CONNECTOR J3
PIN 1 - 103
PIN 2 - 103A
PIN 3 - 56B (14GA)
PIN 4 - 56A
PIN 5 - 84
PIN 6 - CANH
PIN 7 - PLUGGED
PIN 8 - 57A
PIN 9 - CANL
PIN 10 - 74
PIN 11 - 105
PIN 12 - 104
CONNECTOR J2
SOCKET 1 - 76B
SOCKET 2 - 96
SOCKET 3 - 76A
SOCKET 4 - PLUGGED
SOCKET 5 - PLUGGED
SOCKET 6 - JUMPER WITH SOCKET 7
SOCKET 7 - JUMPER WITH SOCKET 6
SOCKET 8 - 68
SOCKET 9 - 54
SOCKET 10- 81
SOCKET 11- 77
SOCKET 12 - 09A
CONNECTOR J1
PIN 1 - 56 (14GA)
PIN 2 - 103
PIN 3 - 103A
PIN 4 - 84
PIN 5 - 74
PIN 6 - 09
PIN 7 - 02
PIN 8 - 57A
PIN 9 - PLUGGED
PIN 10 -PLUGGED
PIN 11 -PLUGGED
PIN 12 -PLUGGED
CONNECTOR J2
SOCKET 1 - 96
SOCKET 2 - 76
SOCKET 3 - 81
SOCKET 4 -77(Engine run=GND)
SOCKET 5 - 68
SOCKET 6 - PLUGGED
SOCKET 7 - CANH
SOCKET 8 - CANL
SOCKET 9 - PLUGGED
SOCKET 10 -PLUGGED
SOCKET 11 -PLUGGED
SOCKET 12 -PLUGGED
J1
J2
J3
J4
X22 CONN
A - 09
B - 02
G - 105
H - 104
56A
54
56
56B
76A
76B
02
76
SPL09
SPL02
SPL104
SPL105
76ACR
56ACR
76A
56
56B
56A
54
76B
76
02
T0 RELAY
T0 RELAY
56ACR
76ACR
NOTE:
The relays are mounted
to the outside of the base
control box.
SPCANH
SPCANL
R=120Ω
D09
31 2
64 5
97 8 1210 11
31 2
64 5
97 8 1210 11
31 2
64 5
7 8
31 2
64 5
7 8
CONNECTOR
H G
TO X22
A
B
T0 RELAY
56ACR
T0 RELAY
76ACR
TO BASE BOX
ENCLOSURE
TO ENGINE
HARNESS
56(FROM CB3)
56B
56A
103
103
103A
103A
84
84
57A
57A
74
74
R=
120
ohm
09
02
D09
SP09
54
09A
76A
76B
SP02
96
96
76
JMPR
81
81
77(ENGINE RUN= GND)
68
68
77(ENGINE RUN= GND)
105
104
CANL
CANH
CANH
CANL
56A
54
56
56B
76B
76A
76
02
105
104
02
09
SP104
SP105
R=
120
SPCANH
SPCANL
3.16 Interface Harness - Deutz D2.9L
