Skyjack SJ46 AJ+ Service Manual

41
229042ABASJ46 AJ+, SJ46 AJ, SJ51 AJ
Maximum Platform Capacity Section 2 – Maintenance Tables and Diagrams
WARNING
Do not use tires other than those specified for this machine. Do not mix different types of tires. Tires other
than those specified can adversely affect stability. Failure to operate with matched, approved tires in good
condition can result in death or serious injury. Replace tires with the exact, Skyjack-approved types only.
IMPORTANT
For the proper functioning of each axle differential, all four wheels must have same tire size installed at all
times. Failure to comply with this requirement will reduce the life of the differentials and reduce the overall
mobility of the MEWP.
Model Type Brand Size Ply Rating
SJ46 AJ+ ANSI
Solid
Trelleborg Brawler HPS 31x10-20 N/A
Solid non-marking
SJ46 AJ CE & AS
Foam Carlisle TR-501 12x16.5 10
Foam non-marking OTR 315/55D20 12
2091AA
2.8 Maximum Platform CapacityTable
SJ46 AJ+ ANSI/CSA
SJ46 AJ & SJ51 AJ
CE & AS
without attachment with attachment
Total Capacity*
300 kg (660 lb) 272 kg (600 lb) 227 kg (500 lb)
2 Persons 1 Person 2 Persons
Maximum Wind 12.5 m/s (28 mph) 12.5 m/s (28 mph) 12.5 m/s (28 mph)
Maximum Side Force 400N (90 lb) 200 N (45 lb) 400N (90 lb)
2043AA
2.9 Tire SpecificationsTable
WARNING
* DRIVING ON A SLOPE
▪
When driving on a slope greater than 30%, the platform capacity is limited to 136 kg (300 lb).
▪
The platform must be between the non-steer wheels and must be on the downside of the hill.
▪
When the slope increases to above 45%, the forward drive is disabled but reverse drive remains
active.
