Skyjack SJ46 AJ+ Service Manual

147
229042ABASJ46 AJ+, SJ46 AJ, SJ51 AJ
Electrical System - CE & AS Section 4 – Troubleshooting Information
5. Loose or broken wire #54A from base terminal
strip to relay 54ACR.
Check continuity. Replace if defective.
6. Loose or broken wire #11 from base terminal
block to relay 54ACR.
Check continuity. Replace if defective.
7. Defective relay 54ACR. Check relay. Replace if defective.
8. Defective glow plugs. Check glow plugs. Replace if defective.
NOTE
For other glow plug related problems, consult engine manufacturer’s manual.
4.3-6 All Base Control Console Inoperative
1. Loose or broken wire #10 from base emergency
stop switch S3 to ignition/ pump switch S5.
Check continuity. Replace if defective.
2. Defective ignition/ pump switch S5. Check continuity through switch when activated.
Replace if defective.
3. Loose or broken wire #10A from ignition/pump
switch S5 to base terminal block.
Check continuity. Replace if defective.
4. Loose or broken wire #10A from base terminal
block to diode D10A.
Check continuity. Replace if defective.
5. Open or defective diode D10A. Check diode. Replace if defective.
6. Loose or broken wire #20 from diode D10A to
base terminal block.
Check continuity. Replace if defective.
7. Missing or broken jumper JMPR3 on base
terminal block between wires #20 and #21.
Check for jumper. Replace if missing or broken.
NOTE
Jumper is removed if equipped with generator option.
8. Loose or broken wire #21 from base terminal
block to relay 21CR.
Check continuity. Replace if defective.
9. Loose or broken wire #02 from base terminal
block to relay 21CR.
Check continuity. Replace if defective.
10. Loose or broken wire #09 from base terminal
block to relay 21CR. (ANSI/CSA)
Check continuity. Replace if defective.
11. Loose or broken wire #09 from base terminal
block to relay 59CR. (CE)
Check continuity. Replace if defective.
12. Loose or broken wire #162A from relay 59CR to
base terminal block. (CE)
Check continuity. Replace if defective.
13. Loose or broken wire #162A from base terminal
block to relay 21CR. (CE)
Check continuity. Replace if defective.
