69
229042ABA
SJ46 AJ+, SJ46 AJ, SJ51 AJ
Pressure Reducing Valve Ports
Section 3 – System Component Identification and Schematics
3
T
o Hydraulic T
ank
1
T
o Rotary Manifold Port 6
2
T
o Brake Manifold
2SPD Port
3.12
Press
ure
Reduc
ing
V
alve
P
orts
To
order
go
to
Discount-Equipment.com
66
68
