Skyjack SJ46 AJ+ Service Manual

A B C D E F G H
V
Z
Y
X
W
91
229042ABASJ46 AJ+, SJ46 AJ, SJ51 AJ
3.31 Oil Cooler and 3.5 kW Generator Base Control Box Wiring
M152418AB_148596AB
02
SOLENOID VALVE
TO GENERATOR
INSERT BLACK WIRE ‘85’ INTO
PLUG ‘B’ - POSITION ‘21’
INSERT WHITE WIRE ‘02’ INTO
TERMINAL BLOCK ‘02’
1
13
21
2412
1
PLUG B
57ACR 79CR
01CR 49CR
86CR
86A
86
03B
20A
03
03B
09 09
CONNECTOR
CONNECTOR
POWER STUD
INSTALL UNDER COOLER MOUNTING BOLT
TO EMERG. PUMP
03
1
TO TEMPERATURE SWITCH
1
00
TO COOLER FAN
86A
03B
86
RELAY SOCKET
TOP VIEW
-DETAIL A-
INSERT WIRES ‘03B’, ‘86’ & ‘86A’ INTO
EXISTING RELAY BLOCK, PER DETAIL ‘A’
INSERT WIRE ‘09’ INTO
TERMINAL BLOCK ‘09’
02 (EXISTING)
Base Control Console -
3.5 kW Generator Wiring
Base Control Console -
Oil Cooler Wiring
