Skyjack SJ46 AJ+ Service Manual

A B C D E F G H
V
Z
Y
X
W
77
229042ABASJ46 AJ+, SJ46 AJ, SJ51 AJ
3.17 Interface Harness - Deutz D2011
M218415AF-1
31 2
64 5
7 8
31 2
64 5
7 8
31 2
64 5
97 8 1210 11
31 2
4
5 6
97 8 1210 11
T0 RELAY
57ACR
T0 RELAY
68CR
T0 RELAY
56ACR
9
T0 RELAY
00ACR
TO BASE BOX
ENCLOSURE
56(FROM CB3)
54A
74
96
02
00A(ENGINE RUN= GND)
02
77(ENGINE RUN= GND)
57B
76
103
103
76
57A
SP02
X22
DIAG PORT
09
74
84
84
104
105
106
68
68A
96
TO ENGINE
HARNESS
CANH
CANL
CANH
CANL
B L K A
09
104
105 106
02
57A
54A
57B
02
68
54A
68A
SP54A_1
11
11
02
09
54A
56
SP54A_2
SP09
SP02A
54A
120
R=
00A
09
02
77
SP09A
SP02B
SP54A_3
D54A
77A
76
SP76
CONNECTOR J3
PIN 1 - 56
PIN 2 - 02
PIN 3 - 00A(GND)
PIN 4 - 57B
PIN 5 - 77
PIN 6 - 103
PIN 7 - 76
PIN 8 - 74
PIN 9 - 84
PIN 10 - 104
PIN 11 - 105
PIN 12 - 106
CONNECTOR J2
SOCKET 1 - 68A
SOCKET 2 - 96
SOCKET 3 - CANH
SOCKET 4 - CANL
SOCKET 5 - 11
SOCKET 6 - PLUGGED
SOCKET 7 - PLUGGED
SOCKET 8 - PLUGGED
SOCKET 9 - PLUGGED
SOCKET 10- PLUGGED
SOCKET 11- PLUGGED
SOCKET 12 - PLUGGED
CONNECTOR J1
PIN 1 - 56
PIN 2 - 103
PIN 3 - PLUGGED
PIN 4 - 84
PIN 5 - 74
PIN 6 - 09
PIN 7 - 02
PIN 8 - 57A
PIN 9 - 54A
PIN 10 -PLUGGED
PIN 11 -PLUGGED
PIN 12 -PLUGGED
CONNECTOR J2
SOCKET 1 - 96
SOCKET 2 - 76
SOCKET 3 - PLUGGED
SOCKET 4 -77(Engine run=GND)
SOCKET 5 - 68
SOCKET 6 - PLUGGED
SOCKET 7 - CANH
SOCKET 8 - CANL
SOCKET 9 - PLUGGED
SOCKET 10 -PLUGGED
SOCKET 11 -PLUGGED
SOCKET 12 -PLUGGED
J1
J2
J3
J4
X22 CONN
A - 09
B - 106
K - 104
L - 105
SPL02
SPL54A_1
SPL54A_2
57ACR
68CR
56ACR
57A
56
54A
09
02
02
02
57B
54A
54A
68A
68
02
68
54A
68A
57A
02
54A
57B
09
02
56
54A
T0 RELAY
57ACR
T0 RELAY
68CR
T0 RELAY
56ACR
SPL02A
SPL09
SPCANH
SPCANL
R=120Ω
00ACR
00A
02
77
09
T0 RELAY
00ACR
SPL54A_3
SPL02B
D54A
00A
09
02
77
SPL76
NOTE:
The relays are mounted
to the outside of the base
control box.
