229042ABA SJ46 AJ+, SJ46 AJ, SJ51 AJ
Section 5 – Procedures Platform
P3 (White) Master Controller: SMB1-105
Pin Wire Function Input/Output Type I/O Name Label
1 119 Load Zone Border Lamp Digital Output P30 DOUT1
2 01A Emergency Pump Relay Digital Output P37 DOUT8
3 23 Steer Right Digital Output P36 DOUT7
4 118A Overload Alarm/lamp Digital Output P35 DOUT6
5 65 Axle Lock Digital Output P34 DOUT5
6 120 Low capacity zone lamp Digital Output P3B DOUT12
7 85 Generator Solenoid Digital Output P3A DOUT11
8 68 Engine Run Enable Digital Output P39 DOUT10
9 57A Engine Start Digital Output P38 DOUT9
10 20 All-Motion Alarm Digital Output P3F DOUT16
11 120A High capacity zone lamp Digital Output P3E DOUT15
12 Not Used Digital Output P5C DOUT14
13 24 Steer Left Digital Output P31 DOUT2
14 Not Used Analog Input AN16 AIN01
15 Not Used Analog Input AN17 AIN02
16 Not Used Analog Input AN18 AIN03
17 Not Used Analog Input AN19 AIN04
18 Not Used Analog Input AN20 AIN05
19 Not Used Analog Input AN21 AIN06
20 128 Angle Sensor - Chassis Analog Input AN22 AIN07
21 Not Used Analog Input AN23 AIN08
22 Not Used Analog Input AN25 AIN09
23 11 Propane Run Digital Output P3C DOUT13
24 21A Dump Valve Digital Output P32 DOUT3
25 45A Motor 2 Speed Digital Output P33 DOUT4
26 40B Platform Level Down Digital Input PC2 DIN19
27 Main Boom Creep (used on 86) Digital Input PC5 DIN20
28 37B Platform Rotate Right Digital Input PC8 DIN21
29 36B Platform Rotate Left Digital Input PCA DIN22
30 Riser Down Digital Input PCC DIN23
31 Riser Up Digital Input PCE DIN24
32 121 load zone safety limit (Main) Digital Input PD0 DIN25
33 122 load zone safety limit (Fly) Digital Output PF4 DIN26
34 26 Holding Brake Off Digital Output P06 DOUT17
35 165 Diff Lock Digital Output P07 DOUT18
