Skyjack SJ46 AJ+ Service Manual

211
229042ABASJ46 AJ+, SJ46 AJ, SJ51 AJ
Platform Section 5 – Procedures
SCM Calibration Flowchart (continued)
Continued from the previous page
328 lbs used as an example.
Value = the platform weight
Weight Calibration Complete
Calibration Save/Exit screen.
Press the Save exit button to
save the calibration and exit,
or press up/+ or down/- to
return to calibration.
SP1/2 = the value that the controller will
indicate an overload in each capacity zone
Value = Net weight: the weight
currently on the platform.
The value displayed
is the actual weight
on the platform.
SP# CAL is the
weight the weight
the machine is
calibrated to go into
overload in each
capacity zone.
Pressing Save/Exit
on these screens
will set the SP1/SP2
to whatever weight
is on the platform.
Do not reset Set
Points 1 or 2 unless
directed to do so
by Skyjack.
