Section 3 – Familiarization Component Identification
FAMILIARIZATION
3.1 Component Identification
Manual Storage
Box
Section 3.2
Fork/Lifting Attachment
Section 4.2-9
Engine Compartment
Section 4.2-7
Boom
Section 4.2-8
Lifting Points
Section 6.2
Frame
Section 4.2-6
Wheel/Tire Assembly,
Drive Axle
Section 4.2-6
Tie-down Points
Section 6.3
Control Functions
Section 3.3
Operator’s Cab
Section 3.4-3
Multi-functional
Joystick
Section 3.3-2
Mirror Section
4.2-5
Boom Extension
Cylinder
Section 4.2-4
Boom Lift Cylinder
Section 4.2-4
