Skyjack SJ519 TH - Model SJ519 TH Operators Cab Controls

216939ADA SJ519 TH
82
Section 8 – Labels Model SJ519 TH
Description Label Pictorial
1
Left Side Dash Panel
Turn Signals Switch (if equipped)
▪
Select to signal left.
▪
Select to signal right.
Always wear seat belt .
Absolutely no riders .
This vehicle is equipped with a backup alarm sound .
172942AAZZ
2
Direction Control Lever
Transmission gear selector
3
Hydrostatic Pump Speed Control
Adjust knob to control the speed of the hydrostatic pump
8.1 Model SJ519 TH
Operator’s Cab Controls
P
FWD
REV
OFF
AUX
Flow
Direction
FWD
REV
1
2
3
7
