Skyjack SJ519 TH - Examples on Reading the Capacity Chart

SJ519 TH 216939ADA
63
Use of the Capacity Charts Section 5 – Operation
5.11-2 Examples on Reading the Capacity Chart
The following scenarios show various conditions the operator may encounter:
Examples Load Weight
Forward
Reach
Lift Height
Boom
Angle
Boom Capacity OK to Lift
1
1,134 kg
(2,500 lb)
1.52 m
(5 ft)
4.57 m
(5 ft)
56° E
1,980.8 kg
(4,400 lb)
YES
2
1,225 kg
(2,700 lb)
1.83 m
(6 ft)
3.35 m
(11 ft)
45° D
1,360.8 kg
(3,000 lb)
YES
3
997.9 kg
(2,200 lb)
2.74 m
(9 ft)
2.43 m
(8 ft)
31° D
907.2 kg
(2,000 lb)
NO
4
2,267.96 kg
(5,000 lb)
0.6 m
(2 ft)
3.96 m
(13 ft)
63° B
2,494.75kg
(5,500 lb)
YES
5
2,041.61 kg
(4,500 lb)
3.35 m
(11 ft)
0.6 m
(2 ft)
5° E
861.82 kg
(1,900 lb)
NO
1
220519AAA
SJ519 TH
20
15
10
5
0
0510
A
B
C
D
E
F
A
B
C
D
E
F
10°
20°
30°
40°
50°
60°
70°
Sample Chart
Forks: 1.5 x 4 x 48 Pallet
1.5 x 4 x 60 Pallet
1.5 x 4 x 48 Tapered lumber
Rated capacity at 24” Load Center
In the event the load capacity of
the attachment or forks is less
than this load chart capacity, do
not exceed capacity marked on
the attachment or fork.
FORWARD REACH - ft
LIFT HEIGHT - ft
1900 lb (862 kg)
2000 lb (907 kg)
3000 lb (1361 kg)
4400 lb (1995 kg)
5500 lb (2495 kg)
0°
-3°
SAMPLE ONLY - USE CHART IN CAB
1
4
2
3
5
