Skyjack SJ519 TH - Test Horn; Test Lights (if Equipped)

SJ519 TH 216939ADA
45
Function Tests Section 4 – Pre-operation
P
FWD
REV
OFF
AUX
Flow
Direction
FWD
REV
4.3-2 Test Horn
1. Push horn on steering wheel.
▪
Result: Horn should sound.
4.3-3 Test Lights (If Equipped)
1. Use a spotter to check if all lights are working
well. The spotter should maintain a safe distance
from telehandler.
2. Turn parking brake switch
1
to off position.
▪
Result: Rear brake lights should turn off.
3. Depress service brake pedal.
▪
Result: Rear brake lights should turn on.
4. Select boom lights switch
2
(if equipped) to
on position.
▪
Result: Boom lights should turn on.
5. Select the front work lights switch
3
(if
equipped) to on position.
▪
Result: Front work lights should turn on.
6. Select the front/rear work lights switch
4
(if
equipped) to on position.
▪
Result: Front/rear work lights should turn on.
7. Select low beam headlights switch
5
to on
position.
▪
Result: low beam headlights and tail light
should turn on.
8. Select high beam headlights switch
6
to on
position.
▪
Result: High beam headlights & taillights
should turn on.
1
5432
6
