Section 5 – Operation Handling Loads at Variable Heights
5.8 Handling Loads at Variable
Heights
WARNING
▪
Handle only loads within the rated capacity as
shown on the capacity charts mounted on the
telehandler.
▪
Ensure the capacity chart used corresponds
to the attachment fitted to the telehandler.
▪
Use only manufacturer’s approved
attachments. The use of non-approved
attachments may cause telehandler instability
and tip-over, which may result in death or
severe injury to operators or bystanders.
▪
Ensure that the load center for the load is at
or within 61 cm (24 in) of forks (refer to Figure
23).
▪
Use a spotter when possible to assist in
handling the load (refer to Section 1.3).
5.8-1 Picking up a Load
1. Move direction control lever to neutral and press
the park brake switch to on position.
2. Check that telehandler is level using the level
indicator.
3. Ensure the forks are as far apart as possible for
the width of the load. This increases the stability
of the load and the lift.
4. Approach load slowly, raise and extend the
boom until the forks are perpendicular to the
load.
5. Extend and lower the boom to insert the forks
under load; making sure not to extend forks past
the load so that any loads or equipment behind
the load being lifted are not damaged, then raise
it 12.7 cm to 25.4 cm (5 to 10 in).
6. Tilt forks backwards. Fully retract the boom then
check telehandler stability before transporting
the load (refer to Section 5.7-2).
5.8-2 Placing a Load
1. Move direction control lever to neutral and press
the park brake switch to on position.
2. Raise and extend boom until the load is
perpendicular over placement point.
3. Place the load in a horizontal position and lower
boom until the load is completely off the forks.
Do not apply downward force with the forks.
4. Free the forks gradually by lowering and
retracting the boom alternately.
5. When forks are clear of the load, fully retract the
boom then return to transport position.
5.9 Parking and Shutting
Down the Telehandler
CAUTION
Operator should observe the following when
parking the telehandler.
▪
Avoid parking on slopes or near excavation,
ditches or soft fills. If parking on slopes
cannot be avoided, ensure frame is leveled
and telehandler is positioned at a right angle
across the slope.
▪
Avoid parking on roads or highways. If it
cannot be avoided, ensure to display warning
flags during the day and flares or flashing
lights at night.
1. Position telehandler on a firm and level surface.
WARNING
Engage the park brake switch before exiting
the operator’s cab.
2. Bring telehandler to a full stop.
3. With foot on service brake, press the park brake
switch to on position.
4. Move direction control lever to neutral position.
5. Release service brake and ensure machine does
not roll.
6. Retract boom fully and position attachment on
ground.
7. Allow engine to idle for 3 to 5 minutes.
8. Shut off engine and remove key.
WARNING
Ensure that you maintain three points of contact to
mount/dismount the cab.
9. Dismount from telehandler.
10. Chock or block wheels to prevent telehandler
from rolling.
