70
SJ6826 RT, SJ6832 RT
221587ABA
Section 6 – Additional Procedures Fold the guardrails
16. Remove the locking pins on the right side
guardrail.
17. Fold down the right side guardrail.
18. Remove all the locking pins on the left side
guardrail.
19. Fold down the left side guardrail.
20. With the gate closed, remove all the locking pins
on the entrance side guardrail.
21. Fold down the entrance side guardrail.
22. Use the MEWP ladder to exit the platform.
6.6-2 Unfold the guardrail system up
1. Make sure the MEWP is on firm, level ground.
2. Make sure you fully lower the platform.
3. Push the emergency-stop button on the base
control console.
4. Turn the main power disconnect switch to the
off position.
WARNING
Fall Hazard. Use the three points of contact
principle when you use the MEWP ladder to enter
and exit the platform. If you do not obey, there is a
risk of death or serious injury..
5. Use the MEWP ladder to enter the platform.
6. Close the gate.
WARNING
Fall hazard. To prevent a fall, keep away from the
sides of the platform when you fold or unfold the
guardrails. If you do not obey, there is a risk of
death or serious injury.
WARNING
Fall hazard. Install each lock-pin correctly with
the detent ball of each lock-pin fully through the
guardrail. The guardrail system must be in the
vertical position. An incorrectly locked guardrail
can cause a fall, which can cause death or serious
injury.
7. Unfold the entrance side guardrail.
8. Put in all locking pins to lock the entrance side
guardrail in position.
9. Unfold the left side guardrail.
10. Put in all locking pins to lock the left side
guardrail in position.
11. Unfold the right side guardrail.
12. Put in all locking pins to lock the right side
guardrail in position.
13. Unfold the left-side extension guardrail.
14. Put in the locking pin to lock the left-side
extension guardrail in position.
15. Unfold the right-side extension guardrail and the
front guardrail.
To Next Page
