IDP-782 - Hardware Guide
The IDP-782 is available with either the standard satellite antenna (Figure 7) or the low elevation satellite
antenna (Figure 8).
Figure 7: Standard Satellite Antenna
Figure 8: Low Elevation Satellite Antenna
