IDP-782 - Hardware Guide
3.15.3.1 Standard Antenna
Parameter Value
Mass Side entry with 5 m cable: 360 g
Enclosure Material Lexan EXL 9330
Color Code 8T9D076 (white)
Sealing Gasket Material Santoprene
®
Figure 16: Standard Antenna Height Dimensions (mm)
3.15.3.2 Low Elevation Antenna
Parameter Value
Mass Side entry with 5 m cable: 365 g
Enclosure Material Lexan EXL 9330
Color Code 8T9D076 (white)
Sealing Gasket Material Santoprene
®
T213, Version 02
46
© SkyWave Proprietary
