Table 2: Terminal Input Currents
Mode of Operation Condition Satellite
Tx
Satellite
Rx
GPS Cellular Current
Satellite Rx
(C/No=42dBHz)
Burst current for Rx freq.
1540045000 1000 2
OFF ON OFF OFF 64.1 mA
GPS Rx
(C/No=42dBHz)
Cold fix current during u-blox on
command
OFF OFF ON OFF 32.4 mA
Hot fix current during u-blox on
command
OFF OFF ON OFF 30.1 mA
IDP-782 GPRS - Rx
(Idle)
850 MHz band; RSSI=10-12 OFF OFF OFF ON 36.5 mA
IDP-782 HSPA - 2G
Rx (Idle)
850 MHz band; RSSI=10-12 OFF OFF OFF ON 34.5 mA
IDP-782 HSPA - 3G
Rx (Idle)
850 MHz band; RSSI=10-12 OFF OFF OFF ON 34.1 mA
Satellite Tx mode Burst current ON OFF OFF OFF 1078.7 mA
IDP-782 GPRS - Tx
max
850 MHz band; burst current peak OFF OFF OFF ON 392.3 mA
50 MHz band; average current OFF OFF OFF ON 112.9 mA
IDP-782 HSPA - 2G Tx
max
850 MHz band; GPRS; burst current
peak
OFF OFF OFF ON 557.7 mA
850 MHz band; GPRS; average current OFF OFF OFF ON 153.5 mA
IDP-782 HSPA - 3G Tx
max
HSPA+ 850 MHz band OFF OFF OFF ON 231.0 mA
Standby IDP modem powered on, cellular
modem powered off
OFF OFF OFF OFF 13.2 mA
Sleep IDP modem sleep mode=0, power LED
on
OFF OFF OFF OFF 1.979 mA
Sleep (no LED) IDP modem sleep mode=0, power LED
off
OFF OFF OFF OFF 0.110 mA
±15%
Standby (backup battery) IDP modem powered on, cellular modem
powered off, LED on
OFF OFF OFF OFF
12.9 mA
Sleep (backup battery) IDP modem sleep mode=0, LED off
OFF OFF OFF OFF
138 µA
