IDP-782 - Hardware Guide
3.13 IDP-782 GPRS - Cellular Module
Type
u-blox SARA-G3 series (SARA-G350)
GPRS Module
GSM 850/900/1800/1900 MHz
Output Power
Class 4: 33 dBm for EGSM850/900
Class 1: 30 dBm for GSM 1800/1900
Input Power
Peak current of 1.5 A typical.
Module Supply Peak Current: peak of current consumption through the VCC pads
during a GSM 1-slot transmit burst, with a matched antenna
Data Transfer
GPRS
l Multislot Class 10
l Full PBCCH support
l Coding Scheme 1 – 4
CSD
l GSM maximum 9.6 kb/s
Antenna Detect
Output DC current pulse: 20 µA typical
Output DC current pulse period 3.7 to 8.1 ms, 5.4 typical
3.14 IDP-782 HSPA - Cellular Module
Type
u-blox LISA-U2 series (LISA-U200)
HSPA Module
GSM/GPRS/EDGE
Quad-band support:
l GSM 850, E-SGM 900, DCS 1800, and PCS 1900 MHz
HSPA
Six-band support:
l Band I (2100 MHz), Band II (1900 MHz), Band IV (1700 MHz), Band V (850 MHz),
Band VI (800 MHz), Band VIII (900 MHz)
