IDP-782 - Hardware Guide
3 Specifications
3.1 Temperature
Parameter Value -40° to +85°C
Operating Temperature
excluding batteries
-40° to +85°C
Storage Temperature
excluding batteries -40° to +85°C
Reverse Polarity Protection -40 V maximum
3.1.1 Backup Battery Temperature
Table 1 defines the backup battery's temperature specifications.
Table 1: Terminal with Backup Battery Temperature Specifications
Backup Battery
Charge Temperature Range 0°C to +45°C
Discharge Temperature Range -10°C to +60°C
Storage Range
≤ 1 month
≤ 3 months
≤ 1 year
Ideal for long-term storage
-20°C to +45°C
-20°C to +35°C
0°C to +30°C
10°C to +25°C
3.2 Electrical
3.2.1 Input Range
Parameter Value
Power Supply Voltage 9 to 32 V DC
3.2.2 Power Consumption
Typical values at ambient temperature with a terminal input voltage of 12 VDC.
Table 2 shows current without the data cable connected.
T213, Version 02
24
© SkyWave Proprietary
