IDP-782 - Hardware Guide
Output Power
GPRS
Class 4: 33 dBm for GSM/E-GSM bands
Class 1: 30 dBm for DCS/PCS bands
Edge
Class E2 (27 dBm) for GSM/E-GSM bands
Class E2 (26 dBm) for DCS/PCS bands
HSPA
Class 3 (24 dBm) for WCDMA/HSDPA/HSUPA mode
Input Power
Peak currents of 1.8 A typical, 2 A maximum.
Module supply peak current consumption:
peak of current consumption through the VCC pins during a GSM 1-slot Tx burst at
maximum Tx power, with a matched antenna
Data Transfer
GPRS
l GPRS multislot class 334, coding scheme CS1-CS4, up to 107 kb/s DL, 85.6 kb/s
UL
l GPRS multislot class 125, coding scheme CS1-CS4, up to 85.6 kb/s DL/UL
l EDGE multislot class 334, coding scheme MCS1-MCS9, up to 296 kb/s DL,
236.8 kb/s UL
l EDGE multislot class 125, coding scheme MCS1-MCS9, up to 236.8 kb/s DL/UL
HSPA
l HSUPA category 6, up to 5.76 Mb/s UL
l HSDPA category 8 up to 7.2 Mb/s DL
l WCDMA PS data up to 384 kb/s DL/UL
3.15 Mechanical
3.15.1 Transceiver
Parameter Value
Dimensions 114.5 x 136 x 41 mm (LxWxH)
Mass 250 g
Enclosure Material Lexan Plastic
Backup Battery Mass 80 g
T213, Version 02
44
© SkyWave Proprietary
