IDP-782 - Hardware Guide
3.15.2 Cellular Antenna
Parameter Value
Mass 80 g including cable
Dimensions 116.0 x 21.5 x 4.3 mm (LxWxH)
Cable length 2.5 m
Mounting Adhesive backing
3.15.3 Satellite Antenna
Figure 15: Satellite Antenna (standard and low elevation) - Bottom View (mm)
T213, Version 02
45
