CHAPTER 2
GETTING STARTED
22 smarttech.com/kb/171225
To connect a speakers
Connect the speakers’ 3.5 mm cable to the speaker receptacle on your document camera's
left side connection panel.
Shooting area, overhead light, and anti-glare
sheet
Shooting area
The shooting area can view a maximum area of 17 4/8" x 9 6/8" (44.5 cm x 24.8 cm).
To rotate the image
Adjust the camera head to shooting area, and press ROTATE on the control panel or remote
control.
To mirror the image
1. Press the MENU button on the control panel, and then select the Image tab.
2.
Use the down arrow button on the control panel or remote control to select MIRROR.
3.
Press and select ON.
4. Press the MENU button on the control panel to close the menu.
Overhead light
The camera head has a bright LED overhead light to enhance the lighting condition.
To power on the overhead light
Press the LAMP button on your document camera’s control panel or remote control to power
the overhead light on and off.
Anti-glare sheet
The anti-glare sheet is a special coated film that helps eliminate any glare that could be
encountered while displaying glossy objects, such as magazines and photos. Place the anti-glare
sheet on top of an object to reduce reflected light.
