Operation in a Unicable System
136 smart CX01
8 Operation in a Unicable System
8.1 Via Unicable
The HDTV receiver smart CX01 allows for changing the receiving mode to the uni-
cable standard. This makes it possible - depending on the antenna type - to con-
nect up to eight independent receivers to only one main line.
For this, an own IF channel and a corresponding frequency should be set for each
receiver via the settings menu.
Allocation of channels and frequencies depends on the used LNBs and/or multi-
switches.
The data sheet and the technical documentation of your LNB and/or multi-switch
include an allocation table similar to the following table.
8.2 Allocation of IF channels and frequencies
Receiver IF channel Exemp. frequency (MHz) Frequency (MHz)
Receiver 1 1 1284
Receiver 2 2 1400
Receiver 3 3 1516
Receiver 4 4 1632
Receiver 5 5 1748
Receiver 6 6 1864
Receiver 7 7 1980
Receiver 8 8 2096
)
¾ Enter the frequencies of your receiving system into the last col-
umn of the table so that all relevant information is quickly
available. Rule of thumb: highest frequency Æ shortest cable
path.
