SMC Networks HRSH200-A*-20 Series User Manual

HRX-OM-Q026-B
Chapter 5 Display and setting of various functions
5.21 Communication function HRSH Series
5-84
Contact output signal 3 selected alarm Setting and checking
61. Press the [SEL] key once.
The set screen of contact output signal 3 selected alarm is displayed on the digital
display.
PV
SV
62. Select contact output signal 3 selected alarm from the table below with [▲] key or [▼]
key, and confirm by pressing “SEL”.
Table 5.21-32 List of set value
Set value Explanation
Initial value
(Default setting)
Setting/checking are not available unless the
function setting of digial output 1 is selected
alarm status signal.
to
Sets selected alarm
Set range is AL.01 to AL.48.
63. Press the [MENU] key once.
Return to the main screen (screen displaying the circulating fluid temperature).
PV
SV
