SMC Networks JXC91 User Manual

-12-
No.SFOD-OMT0006-F
3. Specifications
3.1 Specifications
Basic specifications of the product.
Item
Specifications
Compatible motor
Step motor (servo 24 VDC)
Power supply
Power supply voltage: 24 VDC±10%
Current consumption
130mA or less (Controller)
Refer to the specification of actuator to be connected for total power
consumption.
Compatible encoder
Incremental A/B phase (800 pulse/rotation)
Memory
EEPROM
LED display
LED
Details
L/A1
Link/Act 1
L/A2
Link/Act 2
PWR
Power supply
ALM
Alarm status
MS
Controller status
NS
Communication status
Locking
With unlocking terminal
Cable length
Actuator cable: 20 m or less
Cooling method
Air-cooling type
Operating temperature range:
0°C to 40°C (version S1.*/S2.*/V1.*/V2.*)
0°C to 55°C (Version S3.*/V3.* or later)
No freezing
Operating humidity range
90% RH or less (No condensation)
Insulation resistance
Between the external terminals and case
50 MΩ (500 VDC)
Weight
210 g (Screw mounting type)
230 g (DIN rail mounting type)
[EtherNet/IP communication]
Item
Specifications
Protocol
EtherNet/IP
TM
(Conformance test version CT-12)
Communication speed
10/100 Mbps (automatic negotiation)
Communication cable
Standard Ethernet cable (STP, CAT5 or higher, 100BASE-TX)
Communication method
Full duplex/Half duplex (automatic negotiation)
Setup file
EDS file (Download from SMC website)
Occupied area
Input 36 byte/Output 36 byte
IP address setting range
Setting by rotary switch: 192.168.1.1 to 254
Via DHCP server: Arbitrary address
Vendor ID
7h (SMC Corporation)
Product type
2Bh (Generic Device)
Product code
D1h

SMC Networks JXC91 Specifications

General

Brand	SMC Networks
Model	JXC91
Category	Controller
Language	English
