7. LED display
7.1 LED display
Refer to the table below for the details of the LED status.
LED
Details
PWR
Power supply
status is displayed
OFF
Power is not supplied
Green LED is ON
Power is supplied
ALM
Controller alarm
status.
OFF
Normal operation
Red LED is ON
Alarm generated
MS
Controller status.
OFF
The controller operating voltage is not
supplied.
Green LED is ON
Operating normally
Green LED is flashing
Setting error
Red LED is flashing
Recoverable error
Red LED is ON
Unrecoverable error
NS
EtherNet/IP
communication
status.
OFF
The controller operating voltage is not supplied
or IP address is not set.
Green LED is ON
EtherNet/IP communications established.
Green LED is flashing
EtherNet/IP communications not established.
Red LED is flashing
EtherNet/IP connection time out
Red LED is ON
IP duplicated
L/A1
Link/Act
OFF
BUS IN side (P1): No Link, No Activity
Green LED is ON
BUS IN side (P1): Link, No Activity
Green LED is flashing
BUS IN side (P1): Link, Activity
L/A2
Link/Act
OFF
BUS OUT side (P2): No Link, Activity
Green LED is ON
BUS OUT side (P2): Link, No Activity
Green LED is flashing
BUS OUT side (P2): Link, Activity
7.2 LED and Controller Status
Refer to the table below for the LED and the controller status.
Controller status
LED description
PWR
ALM
MS
NS
When EtherNet/IP communication is
normal
-
-
Green LED
is ON
Green LED
is ON
Motor
controller
Controller alarm generated
OFF
Red LED is
ON
-
-
Controller system error
generated
Green LED
is ON
Red LED is
ON
-
-
Writing to controller
EEPROM
Green LED
is flashing
-
-
-
-: LED display is unstable
Caution
Do not turn OFF the power supply for the controller or disconnect and connect the cable while the data
is being written to EEPROM (PWR LED (green) is flashing).
 Possibility of incorrect / corrupt data (step data, parameter)
