-19-
No.SFOD-OMT0006-F
2: Manual setting of IP address
IP address is set within the range of 192.168.1.1 to 192.168.1.254.
3: DHCP mode
Obtain IP address from DHCP Server. Obtained IP address is lost when power supply is cut.
4.2 Hardware Configuration
■EDS files and icons
EDS file is required to configure the controller. Furthermore, icons are necessary for the display icon of the
controller on the configurator. The EDS and icon files can be downloaded from the URL given below.
•URL:http://www.smcworld.com
Informative documents → Operation manual --> jxc91_v10.zip
•Contents of jxc91_v10.zip EDS file jxc91_v10.eds
Icon xc91_1.ico
Remote Control mode
If the controller IP address is unknown, change to DHCP mode and re-assign the correct IP
address. When the DHCP server has assigned the correct address, turn off the power
supply and return the unit to Remote control mode.
Upon power-up, the JXC91 will now be available using the address that was set whilst in
DHCP mode.
