Para protect
Para protect
1 to 2
Sets the range in which parameter and step data can be
changed.
1. Basic parameter + Step data (Basic parameter + Return to
origin parameter + Step data)
2. Basic parameter (Basic parameter + Return to origin
parameter)
■
Enable SW
Enable SW
1 to 2
This defines the status of the Enable switch of the teaching
box.
1. Enabled
2. Disabled
■
Unit name
Unit name
Fixed value
Indication of actuator type compatible with the controller.
(Do not change the setting)
-
W-AREA1
W-AREA1
Basic parameter
"Stroke (-)" -
"Stroke (+)"
This is the setting to define the conditions where the
“W-AREA” signal will turn ON. [Unit: mm]
If the current position is within the range between the
W-AREA1 and W-AREA2, “WAREA” will turn ON.
 If W-AREA1 >W-AREA2, the "Parameter ALM" alarm will be
activated. However if W-AREA1= W-AREA2 = 0, “WAREA”
will be OFF and no alarm will be generated.
■
W-AREA2
W-AREA2
Basic parameter
"Stroke (-)" -
"Stroke (+)"
■
ORG
Correct
Link Offset
Fixed value
This is the fixed value for this controller.
( Do not change the setting)
-
Sensor type
Sensor type
Fixed value
This is the fixed value for this controller.
( Do not change the setting)
-
Option 1
Option 1
Fixed value
This is the fixed value for this controller.
( Do not change the setting)
○
Undefine
No. 11
Undefine
No. 11
Fixed value
This is the fixed value for this controller.
( Do not change the setting)
○
Undefine
No. 12
Undefine
No. 12
Fixed value
This is the fixed value for this controller.
( Do not change the setting)
-
1 The range varies depending on the actuator. Please refer to the manual of the actuator for more
details.
