C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 35 –
VLAN
Configuration
Configures IGMP snooping per VLAN interface 137
Port Group
Filtering
Configures multicast groups to be filtered on specified port 139
MLD Snooping Multicast Listener Discovery Snooping 140
Basic
Configuration
Configures global and port settings for multicast filtering 140
VLAN
Configuration
Configures MLD snooping per VLAN interface 143
Port Group
Filtering
Configures multicast groups to be filtered on specified port 145
LLDP Link Layer Discovery Protocol 146
LLDP Configures global LLDP timing parameters, and port-specific
TLV attributes
146
LLDP-MED Configures LLDP-MED attributes, including device location,
emergency call server, and network policy discovery
149
MAC Table Configures address aging, dynamic learning, and static
addresses
155
VLANs Virtual LANs 157
VLAN Membership Configures VLAN groups 158
Ports Specifies default PVID and VLAN attributes 159
Private VLANs
PVLAN
Membership
Configures PVLAN groups 162
Port Isolation Prevents communications between designated ports within
the same private VLAN
163
VCL VLAN Control List
MAC-based VLAN Maps traffic with specified source MAC address to a VLAN 164
Protocol-based
VLAN
165
Protocol to
Group
Creates a protocol group, specifying supported protocols 166
Group to VLAN Maps a protocol group to a VLAN for specified ports 167
Voice VLAN 168
Configuration Configures global settings, including status, voice VLAN ID,
VLAN aging time, and traffic priority; also configures port
settings, including the way in which a port is added to the
Voice VLAN, and blocking non-VoIP addresses
169
OUI Maps the OUI in the source MAC address of ingress packets
to the VoIP device manufacturer
171
QoS 172
Port Classification Configures default traffic class, drop priority, user priority,
drop eligible indicator, classification mode for tagged frames,
and DSCP-based QoS classification
173
Table 4: Main Menu (Continued)
Menu Description Page
