16
(S870) Make sure that the direction of rotation of the heat-shrinking fans is as shown in
figure 2.8.1, otherwise, invert the phase of the power supply plug.
ATTENTION!
In the case which someone wants access to the electrical system, remember to turn off
the power supply and wait at least 5 minutes before operating.
2.9 TECHNICAL DATA FOR THE ELECTRIC CONNECTION
2.10 CONDITIONS OF USE
THE MACHINE NEEDS AN INSTALLATION IN A CLOSED AND WELL AIRED
SURROUNDING, WHERE THERE ARE NOT ANY EXPLOSION OR FIRE DANGEROUS.
THE MINIMUM LIGHTING MUST BE 300 lux.
Make sure that there is enough space for easy application and maintenance. Position the
machine in the planned space with no humidity, flammable materials, gas, and explosives and
making sure that it is level on the floor.
The rated temperatures can vary from +10°C to +40°C, with relative humidity from 30% to 80%
without condensation.
The airborne noise is lower than 70 dB.
IP class rating = IP22
ATTENTION!
The pressure and the plate acoustical power of the machine can change depending on
the material of containers to be packaged. Therefore, the user must perform an
assessment on the noise exposure of his personnel in accordance with the types of
packages worked, so as to equip his operators with suitable personal protection
equipment.
S440
S560 /
S560N
S560NA S870 S870
RATED
VOLTAGE
220-240 V
~
1PH+N+PE
220-240 V
~
1PH+N+PE
220-240 V
~
1PH+N+PE
380-415 V
~
3PH+PE
220-240 V
~
3PH+PE
RATED
FREQUENCY
50-60 Hz 50-60 Hz 50-60 Hz 50-60 Hz 50-60 Hz
RATED
POWER
2300 W 3700 W 3750 W 5100 W 5100 W
RATED
CURRENT
12 A 17.5 A 18 A 8 A 17 A
