Smipack S440 - Machine Limitations and Specifications of Use

32
5.5 MACHINE LIMITATIONS AND SPECIFICATIONS OF USE
• Operating conditions
The following cannot be packaged:
• Products of less than 50 g
(See Tab.“MAXI. PRODUCT DIMENSIONS” at pag. 18)
• Products weighing more than the allowed weight (See Tab.“MAXI. PRODUCT DIMENSIONS”
at pag. 18).
• Products with a height above the allowed size
(See Tab.“MAXI. PRODUCT DIMENSIONS” at
pag. 18).
• Products as large as the netting.
• Liquid products of any kind and density in fragile containers.
• Wet products.
Using your left hand, pull the film
and with your right hand bring the
product inside the packaging tank,
positioning it on the netting, and
being careful to leave 1-2 cm of
space from the sealing blade.
Lower the bell and, the second it
touches the sealing blade, press
with a pressure of 10-15 Kg
(except for the S560NA fig. 5.4.2).
After the audio warning that the
sealing has been completed has
gone off, let go of the handle and,
with the right hand, help the
separation of the residual film to
avoid it sticking to the sealing
blade during cooling.
(S560NA) When the START
push-button is pressed, the bell is
activated and carries out
automatically the stages of
descent, pressure on the sealing
bar and rise.
(S560N e S560NA) The product
will be carried outside by the
motor-driven belt (Fig. 5.4.3).
(S560NA) The machine is
equipped with a safety system
which allows to automatically
make the bell return to the initial
position of readiness for work, in
the case where, during its descent
movement, it encounters any
external resistances.
`
Fig. 5.4.2
Fig. 5.4.3
