Use and maintenance manual S440-S560-S560N-S560NA-S870
poliolefin) with a thickness varying from 10 to 30 µm, also carrying drawings and personalised
wording, as long as the same comply with the provisions of the laws in force. The film, used in
the one-fold execution, can be micro-punched, going through the micro-punches of the
machine itself.
3.8 BAND A CALCULATION
Fig. 3.7.1
MOD. A ø B ø C
S440 500 mm 300 mm 77 mm
S560 600 mm 300 mm 77 mm
S560N 600 mm 300 mm 77 mm
S560NA 600 mm 300 mm 77 mm
S870 800 mm 300 mm 77 mm
Band A = Y+Z+ 50mm
By band "A" we mean the width that the film
must have to package the product.
Fig. 3.8.1
