7.2 RESIDUAL FILM REMOVAL AND MISCELLANEOUS
Before removing any film residues and impurities deposited on the hot parts of the
machine wait until the machine has cooled down
For the cleaning of the lower bell, remove the netting and the larger residues, then go over using
a vacuum cleaner.
7.3 GENERAL CLEANING
Use exclusively a damp cloth to clean the bell. Do not use any detergents or solvents,
since these could damage its transparency.
Clean the machine more frequently if it is used in dusty environments and, in particular, suck
away any dust being deposited on internal electrical components, by removing the machine
back cover.
7.4 REPLACING THE SEALING BLADE
Fig. 7.4.1
• Pull out the machine plug from the mains;
• Unscrew the three
screws 1 locking the
blade;
• Remove the damaged
sealing blade;
• Clean the blade housing;
• Introduce the insulating
PTFE 2 in the central
clamp 3 (if necessary
replace also the PTFE);
• Put in the new sealing
blade, clamping it at the
centre;
• Trim the sealing blade
level with the slot of the
small pistons 4-5;
• Complete the insertion of
the sealing blade in all its
housing;
• Push well down the small
piston 6 using a screwdriver 4, towards the end of the blade, so that it goes into its slot and
tighten its clamping screw 1;
• Trim any PTFE protruding from the central clamp to avoid that it may alter the sealing;
• Make sure that the sealing blade is under tension and that it is correctly positioned in all its
length.
