58
21 • Electrical diagram group S870 3PH 230V
POS. Description spare parts S870 3PH 230V N.
1 FLEXTRON-MASTER KZ010131 1
2 SWITCH EP010230 1
3 FLEXTRON-POWER BASE KZ010138 1
4 TRANSFORMER ET010176 1
5 FUSE EE500011 1
6 FUSE EE500012 6
7 FUSE EE500029 1
8 FUSE SOCKET EE500023 1
9 FUSE SOCKET EE500065 2
10 RELAY SWITCH EE100110 3
11 RELAY EE300113 1
12 FAN EK020022 2
13 FUSE SOCKET TERMINAL EK200004 1
