Use and maintenance manual S440-S560-S560N-S560NA-S870
(S440, S560 and S870)
The screened plate 7 has to be adjusted through controls 5-6 according to the height of the
product to be packaged.
For a good packaging, film sealing must take place at half the product height
.
Fig. 4.12.2
Fig. 4.12.1
