D735 User Manual Setting up the Phone
Connecting a headset
You can use wired as well as wireless headsets with the phone.
• Wired headsets
If you want to use a wired headset, connect it to the RJ audio jack labeled
.
Note: If both a wired and a wireless headset are connected to the phone, incoming calls
will go to the wireless headset.
• Wireless headsets
◦ Connecting the base station of your headset via the Snom EHS Adapter.
1. Connect the plug labeled D3xx/D735 on the 2xRJ12 cable that came with the Snom EHS
Adapter to the jack marked EHS on the D735, and the plug labeled EHS box to the Snom
EHS Adapter's RJ12 jack. For more information, see the illustrated EHS Advanced Quick
Installation Guide at http://wiki.snom.com/Accessories/Documentation.
2. Connect the EHS box to the headset's base station with the 2xRJ45 cable also provided
with the Snom Advanced.
3. Connect the 4P4C/4P4C audio cable that came with the headset to the phone's RJ
audio jack labeled
. Connect the other end to the headset's base station. For more
information, please refer to the headset's user guide.
◦ Connecting the headset to the phone via a Bluetooth-compatible adapter.
Insert the adapter into the USB port of the phone. See also the Quick Start Guides of the Snom
USB BT and the Snom HS BT or the manual of the third-party headset.
Attention: The default settings for USB headsets are VID=0a12:PID=100d:HOOK=38/1
for 8.7.2.11 and higher.
- If your phone is running an earlier firmware version, enter these parameters manually on
the phone's web interface at > Advanced > Audio > text field of "Audio parameters". Click
on the question mark
?
to look up the parameters.
- If you are using a dierent headset, whatever the firmware version, enter the parameters
of the headset manually on the phone's web interface at > Advanced > Audio > text field of
"Audio parameters". Click on the question mark
?
to find out which parameters you need
to use for your respective headset.
