Wire EDM Machine Operation Chapter 11
Copyright November, 98 Page 11-4 Sodick Inc.
P
P
R
R
A
A
C
C
T
T
I
I
C
C
E
E
E
E
X
X
E
E
R
R
C
C
I
I
S
S
E
E
S
S
C
C
H
H
A
A
P
P
T
T
E
E
R
R
T
T
W
W
O
O
Machine Layout Description
1) Give the axis name (letter address) for the following descriptions:
A) Table motion in and out (toward you and away from you).
________________________________________________________________________
B) Table motion left to right.
________________________________________________________________________
C) Upper guide motion left to right.
________________________________________________________________________
D) Upper guide motion in and out (toward you and away from you).
________________________________________________________________________
2) Name the button corresponding to the following descriptions.
A) Activates a program.
________________________________________________________________________
B) Temporarily pauses the program operation.
________________________________________________________________________
C) Acknowledges the fact that you have read a warning or alarm.
________________________________________________________________________
D) Permanently stops the activation of a program.
________________________________________________________________________
3) What does the “KYB / REM” switch do?
________________________________________________________________________
