Switching point for control
The terminal must have an I/O card installed if you wish to forward the control values with the
interface, e.g. to a control light or to a control. The I/O card must be enabled with execute in setup
mode under Program Settings / Percent Weighing / IO Assignments. The output signals are assigned
as follows:
Switching point Signal
S1 Weight value above toler.
S2 disabled
S3 Weight value within toler.
S4 Weight value below toler.
S5 Empty message
S6 Weight value above toler.
The individual inputs and outputs can be customized.
Start mode
If start mode is enabled, the scale freezes the value after reaching the respectively enabled
switching point, and as a result also freezes the signal. The scale can be relieved without disabling
the switching point, and thus without unintentionally starting a new transaction. The frozen state
is only lifted by pressing the F6 Start key in the Control Functions level.
Enable the start mode in setup mode under Program Settings / Percent Weighing / Start Mode.
End controlling
Press the key to start the 2nd Control Functions level and press the F5 Quantity Contr. key;
then delete with the F2 Delete key or delete everything with the key.
6.14.7 Display options with the Info key
Pressing the key gives you the following options:
•
F1 Fixed tare
Displays the stored fixed tare values (fixed tare memory).
•
F3 Perc Contr.
Displays the current target value with tolerance
•
F4 Total
Displays the totals in the totaling memory
•
F5 Plus
Displays all items stored in the totaling memory (item list). The individual items can be
retrieved with the Arrow keys (F3/F4).
•
Tare key
Displays the current tare weight in tare memory.
Press the key after pressing the key.
